Systecon Modular Central Plants and Pumping Systems

A Pioneer in Custom Modular Central Plants

Systecon is a leading manufacturer of custom modular central plants. This includes chiller plants, hot water/steam boiler plants and cogeneration plants; CritiChill® modular indirect evaporative cooling; custom modular pumping systems including VariPrime®; central plant controls; and standard pump packages.

Innovative Modular HVAC Technologies

Systecon works with engineers and contractors to provide the most efficient and advanced modular HVAC solution for a project. One that’s custom-designed for efficiency of both space and energy. The systems are factory-assembled and performance-tested, then delivered to your work site ready for installation. The results are the highest-quality systems with lower installation and operating costs, shorter lead times and less risk to you.

Factory-Built Systems Reduce Risk and Lead Times

New system or retrofit, we provide customers with the most efficient and advanced utility solutions for their projects – custom designed, factory assembled, performance tested and delivered to the worksite ready for installation. Systecon’s factory-built systems offer less risk, shorter project schedules and improved quality compared to traditional field-built systems.

Highest-Quality Systems and Service

Further, Systecon doesn’t just design and build the best-quality systems. They also provide the best-quality service for those systems. Systecon can manage the entire lifecycle of utility systems, from design and assembly, to installation and maintenance, as well as upgrades and retrofit.

Custom Modular Central Plants

Systecon modular central plants are custom designed, factory assembled and performance tested to provide you with the most efficient and advanced system to fit your specific project needs.

Systecon delivers solutions for a variety of system sizes and applications, including systems from 100 to 30,000 GPM and projects from 50 to 10,000 tons in size.

Central Plants Integration

• Chillers: Air-Cooled – Screw, Scroll, Reciprocating, Water Cooled – Centrifugal, Screw, Scroll, Modular
• Boilers: Atmospheric, Power Assisted, Modular, Steam
• Generators
• Cooling Towers: Open Circuit (Induced Draft, Forced Draft), Closed Circuit (Induced Draft, Forced Draft)
• Heat Exchangers: Plate & Frame (Waterside Economizer, Cooling Tower Water Process Systems, Glycol Isolation Systems), Shell & Tube (Steam to Hot Water Systems, Process Isolation)
• Pumps
• Controls and Wiring

Key Features

• Customized solutions for your specific application
• Single-source responsibility
• Component choice
• Industry-leading construction standards
• PLC-based central plant controls
• Performance testing and factory walkthrough
• Simplified installation and start-up

Custom Modular Pumping Systems

Modular pumping systems are typically integrated within a modular central plant. They are custom designed, factory assembled and performance tested to provide the highest-quality solution for your specific project.

A modular pumping system can be applied to chilled water, hot water and condenser water systems. These are applicable to constant speed, primary/secondary and variable primary systems or VariPrime® systems, which include integrated chiller minimum flow bypass and control valve.

Systems can be designed for indoor or outdoor applications with several enclosure options.

Typical System Components

• Structural Base
• Piping and Pipe Supports
• Pumps: Flex Coupled (End Suction, Horizontal Split Case, Vertical Split Case), Closed Coupled (Vertical In-Line, End Suction)
• Motors and Motor Control: Variable Frequency Drives – VFDs (Primary, Secondary, Condenser, Cooling Tower Fan), Combination Starters (Primary, Condenser, Cooling Tower Fan)
• Controls and Wiring
• Mechanical Components: Air Separators and/or Combination Mixer, Expansion Tanks, Suction Diffusers, Valves, Strainers
• All Instrumentation

Optional Components

• Glycol Feed Systems
• Capacitance Tank
• Chemical Treatment
• Heat Exchanger
• Make-Up Water Systems
• Gauges
• Other Specialties

Key Features

• Customized solutions for your specific application
• Single-source responsibility
• Component choice
• Industry-leading construction standards
• PLC-based central plant controls
• Performance testing and factory walkthrough
• Simplified installation and start-up

Standard Pump Packages

These packages provide indoor comfort systems and comprehensive facility solutions for institutional, commercial and industrial uses.

By combining components into standard configurations, Systecon is able to offer pump packages that cost less and require less time to manufacture.

All Systecon Standard Pump Packages come with factory-mounted controls for pump sequencing and remote monitoring. Major system components include pumps, variable frequency drives, headers and structural steel bases.

Design Flexibility

Three basic systems exist:

• Constant Speed (Primary Chilled, Condenser)
• Variable Speed (Secondary Chilled, VS Condenser, Hot)
• Variable Primary Flow (Chilled or Hot)

Major Components

• Pumps: B&G end suction for all products (Model 1510)
• Variable Speed Dives (VFD): Standard ABB product (will always be current)
• Bases:
  • Standard structural steel
  • Interior supports for pumps, piping
  • ¼” diamond plate decking for integral working surface
  • Optional spring isolators
• Controls: All units are pre-programmed for pump sequencing via remote start/stop; pump and VFD failure; remote monitoring of contact points
• Spare I/O available on all units

Applications

• Variable Primary Flow Systems
• Primary/Secondary Flow Systems
• Condenser Systems
• Dual Use Primary/Condenser Systems
• Water Source Heat Pump Systems

Features & Benefits

• Design Flexibility
• Factory Built
• Zero Tolerance Performance Test
• Factory Mounted Controls
• Simplified Field Installation
• Low Installation Costs
• Reduced Space Requirements
